CUDA Support Status#

This page summarizes the generated CUDA paths that are currently exercised by the GRiD developer test suite. For the commands that run these checks, see CUDA Validation And Performance Reporting.

Development testing currently targets sm_120 (RTX 5090) for correctness and performance validation. Earlier compute capabilities (sm_8x) remain supported but are not the active development target.

Joint and interface restrictions#

This is a coverage summary, not a guarantee for every combination of joint type, algorithm, backend and GPU resource budget.

  • Planar and translation joints are decomposed into scalar-joint chains by the parser; mimic joints retain dependent bodies but reduce coordinates.

  • Mimic and spherical minv use a dense inverse of the reduced CRBA matrix rather than the scalar-joint direct-inverse recursion.

  • fk_batched is a NumPy-only single-leaf pose helper. It is not emitted for spherical models or models with more than 32 joints.

  • Multi-stage integrator gradients are not supported for spherical joints or MuJoCo-output twins. plant_step_hessian supports Euler and semi-implicit Euler on fixed and floating bases, via NumPy/CUDA rather than the JAX/PyTorch handles.

See Kinematics (end-effector pose, Jacobian, Hessian) and Integrators and the plant layer for shapes and method scope.

Fixed-Base Robots#

Fixed-base CUDA coverage includes the core dynamics and kinematics paths:

  • Inverse dynamics / RNEA, direct Minv, forward dynamics, ABA, and CRBA.

  • Inverse- and forward-dynamics gradients.

  • End-effector pose, gradient, and Hessian.

  • Fixed-base forced-fallback coverage for oversized gradient kernels.

  • IDSVA-SO (body-frame and world-frame variants) and FDSVA-SO. The dispatcher selects body-frame IDSVA-SO for fixed-base models.

  • Optional per-body external forces (d_f_ext) on RNEA, forward dynamics, ABA, and the inverse-/forward-dynamics gradients (opt-in; nullptr reproduces the no-force path).

  • The grid_plant layer (plant_step, quadratic state/input costs, end-effector position cost, and joint position/velocity/torque log-barriers), emitted as a sibling grid_plant namespace.

  • The centroidal family and its derivatives: com, ccrba, energy, dccrba (∂A/∂q tensor), and cmm_time_variation (Ȧ).

  • The coriolis_matrix C(q,q̇) and the kinetic / potential inertial-parameter energy regressors.

  • Runtime arbitrary multi-EE: end_effector_pose_runtime and end_effector_pose_gradient_runtime (runtime target joint id + per-target offset).

  • Optional runtime-mutable inertial parameters (flag-gated d_inertia_params + set_inertia_params; the baked default is byte-identical).

  • Arbitrary/skew joint <axis> (dense 6-vector S) for inverse_dynamics, crba, aba and minv, including branching models (test_cuda_branching_skew_equivalence.py). This is not a claim of coverage for every skew-joint/backend/derivative combination.

Second-order fixed-base diagnostics are still developer-only. The current green zero-sample set includes iiwa14, go2, gen3, fr3, fetch, and rizon4 (healed 2026-09-15: the upstream flexiv xacro emitted each link’s origin/mass/inertia triple bare, so the local config/robot_assets/rizon4.urdf now wraps them in proper <inertial> elements).

Floating-Base Robots#

Floating-base CUDA coverage includes:

  • Inverse dynamics / RNEA.

  • Direct Minv, forward dynamics, ABA, and CRBA.

  • Inverse- and forward-dynamics gradients.

  • End-effector pose.

  • Opt-in end-effector pose gradient and Hessian checks.

  • IDSVA-SO (world-frame variant, dispatcher-selected) and FDSVA-SO.

  • The centroidal family com / ccrba / energy and the centroidal derivatives dccrba / cmm_time_variation. The two derivatives also emit on big floating-base robots (e.g. g1 / h1_2-floating) via the sweep-pool spill path, so their prior big-floating gap is eliminated.

Floating end-effector Hessian generation uses target-aware spill tiers when needed:

  • Tier 0 keeps all Hessian scratch in shared memory.

  • Tier 1 spills chained d2eeTemp scratch to d_workspace.

  • Tier 2 spills both d2XHom and d2eeTemp to d_workspace.

Tier selection is generated from robot dimensions, base mode, topology-derived transform counts, and GRID_CUDA_TARGET_SHARED_MEM_BYTES. It is not keyed on robot fixture names.

Shared-Memory Fallbacks#

Generated kernels prefer the all-shared path when it fits the target shared memory budget. The default target is 96 KiB:

GRID_CUDA_TARGET_SHARED_MEM_BYTES=98304

Set a lower target to test fallback paths, or a higher target only when the deployment GPU supports the requested dynamic shared memory. Runtime checks compare generated requests against the actual device limit before launch.

Gradient fallback tiers keep the hot dv/* derivative intermediates in shared memory first, then spill larger da/* and df/* buffers when the full shared-memory path is oversized. The emergency tier spills more temporary state to the generated workspace.

Known Caveats#

  • The generated g1 floating-base forward-dynamics inertial-parameter gradient in fp64 requests about 187 KiB of shared memory even at the minimal tier, exceeding the RTX 5090’s per-block limit. An fp64 diagnostic with global scratch is not a supported production launch.

  • Floating IDSVA-SO/FDSVA-SO CUDA generation is now enabled (dispatcher picks idsva_so_world_frame for floating-base). FDSVA-SO on g1_floating requires the selective-spill tier under sm_120’s ~100 KiB per-block dynamic shared-memory cap; the tier selector picks it automatically.

  • Broad nonzero/random floating Hessian coverage is slower than the default smoke suite and remains opt-in.

  • Compute Sanitizer should be run on a supported GPU/driver setup before treating fallback paths as fully sanitizer-clean.

  • Performance tier choices can depend on register pressure and occupancy; use ptxas output and timing kernels on the target GPU before saving local baselines. Tiers are named TIER_SHARED (default) / TIER_LITE / TIER_MINIMAL (the old TIER_PERF alias has been removed — use TIER_SHARED). See Resource-Tier System (v2.0).

  • Robots with mimic joints: non-gradient algorithms are supported, and every gradient now emits a correct mimic-reduced result on both bases — inverse_dynamics_gradient / forward_dynamics_gradient, end_effector_pose_gradient / end_effector_pose_hessian, the second-order idsva_so / fdsva_so, the external-force gradients (f_ext_gradient), and the integrator gradients. No mimic gradient raises NotImplementedError anymore. The centroidal kinematics family (com / ccrba / energy) and the centroidal derivatives (dccrba / cmm_time_variation) are now mimic-reduced as well: the per-body world Jacobian and per-unit motion columns carry the mimic multiplier (α), so all five emit + validate against the mimic-aware RBDReference oracle on fixed-base mimic robots.

  • External-force gradients: f_ext_gradient (∂τ/∂f_ext = −Jᵀ, ∂q̈/∂f_ext = M⁻¹Jᵀ) and the fixed-base f_ext_gradient_dq (−∂Jᵀ/∂q), both with CUDA equivalence tests, and both now fold correctly to the reduced coordinates on mimic robots as well.

Algorithm catalog#

  • Inverse Dynamics via the Recursive Newton Euler Algorithm (RNEA) from Featherstone

  • Composite Rigid Body Algorithm (CRBA) for the joint-space mass matrix and the Articulated Body Algorithm (ABA) for forward dynamics, both from Featherstone

  • The Direct Inverse of Mass Matrix from Carpentier

  • Forward dynamics: qdd = Minv @ (u - RNEA(q, qd, 0))

  • Analytical Gradients of Inverse Dynamics from Carpentier

  • Analytical Gradient of Forward Dynamics from Carpentier

  • End-effector pose, pose gradient (Jacobian), and pose Hessian

  • General-frame geometric Jacobian for an arbitrary target frame in any of the three Pinocchio reference frames (LOCAL, WORLD, LOCAL_WORLD_ALIGNED). The numpy reference additionally provides the Jacobian time-variation J̇ and the operational-space (OSC) inertia Λ = (J·M⁻¹·Jᵀ)⁻¹ — all validated against Pinocchio’s getFrameJacobian/getJointJacobian, computeJointJacobiansTimeVariation, and (J·M⁻¹·Jᵀ)⁻¹. CUDA codegen emits all three as opt-in keys — J (frame_jacobian), J̇ (frame_jacobian_dot), and Λ (osc_inertia) — each validated on-device against the numpy reference across the three frames (Λ is self-contained: it composes M⁻¹ on-device). All three additionally have the full launchable surface (batched *_kernel + 3-mode host writing the gridData d_frame_jacobian / d_frame_jacobian_dot / d_osc_inertia buffers), so they are benchmarkable + bindable; the launchable surface bakes the leaf-EE target + LOCAL_WORLD_ALIGNED frame, while the *_device functions stay the arbitrary-target/-frame entry points

  • Second-Order Inverse Dynamics (IDSVA-SO) from Singh, Russell, & Wensing — the dispatcher selects body-frame for fixed-base and world-frame for floating-base models. See Release measurements for measured performance.

  • Second-Order Forward Dynamics (FDSVA-SO) from Singh, Russell, & Wensing on both fixed and floating bases

  • A time-integrator family: the discrete step x_{k+1} plus its gradient ∂x_{k+1}/∂(x,u) and a fused value-and-gradient variant

  • Optional per-body external forces (f_ext), threaded through RNEA, forward dynamics, ABA, and the inverse-/forward-dynamics gradients. Opt-in (a nullptr/empty default reproduces the no-force path exactly), supplied in the body-local frame (6*NUM_BODIES, body-major) and subtracted from the per-body force.

  • External-force gradients: ∂tau/∂f_ext = -Jᵀ and ∂q̈/∂f_ext = M⁻¹Jᵀ, plus the fixed-base ∂(inverse_dynamics_gradient)/∂f_ext = -∂Jᵀ/∂q

  • A trajectory-optimization-oriented ``grid_plant`` layer (emitted as a sibling grid_plant namespace): a plant_step integrator wrapper, quadratic state/input costs, an end-effector position cost (with Gauss-Newton Hessian), and joint position/velocity/torque log-barriers.

  • The Coriolis matrix C(q,q̇) (with C·q̇ + g(q) = nonlinear_effects)

  • Inertial-parameter energy regressors: kinetic y_KE and potential y_PE (each length 10·NB, with KE = y_KE·π and PE = y_PE·π)

  • The centroidal derivatives: dccrba (the ∂A/∂q tensor, 6×NV×NV) and cmm_time_variation (the centroidal-momentum-matrix time variation Ȧ)

  • Runtime arbitrary multi-EE pose / pose-gradient (end_effector_pose_runtime + _gradient): the end-effector target joint id and a per-target offset become runtime arguments instead of codegen-baked, so one compiled robot serves any leaf/target frame.

  • Runtime-mutable inertial parameters (flag-gated): a set_inertia_params device entry mutates an on-device parameter table (sysID / domain randomization) with no recompile; the baked default path is byte-identical.

  • The joint-torque inertial-parameter regressor (inverse_dynamics_regressor): the classic Y(q, q̇, q̈) with tau = Y·π

  • The analytic regressor gradient (inverse_dynamics_regressor_gradient): ∂Y/∂q and ∂Y/∂q̇, satisfying the contraction identity dY_dx[c]·π == ∂τ/∂x[:,c]

  • The forward-dynamics parameter gradient (forward_dynamics_parameter_gradient): ∂q̈/∂π = −M⁻¹Y

  • Contact-frame wrench mapping (f_ext_contact): maps a contact-frame wrench to the joint-local f_ext layout, with the ∂/∂f_c and ∂/∂q derivatives

  • Runtime multi-target positions (multi_target_position / multi_target_position_gradient): batched runtime-target position queries and their gradients

  • The integrator Hessian (integrator_hessian): the second-order sensitivity of the discrete integrator step

  • The collision family: two-tier config_free collision checking over spherized collision geometry
